Import and export XMI, XML, VPP, Excel, and export diagrams to image files

Interoperability & Integration

Export, import and merge with XML, XMI, MS Excel formats. Import Visio, Rose, Software Artchitect, ERWin, Telelogic Modeler and Enterprise Architect project files without losing any information.

XMI import and export

XML Metadata Interchange (XMI) is an OMG standard for describing the structure for storing UML model in XML format. DB Visual ARCHITECT supports importing and exporting XMI 1.0, 1.2 and 2.1. XMI provides an extendable platform for development team to develop a code generator to generate code from UML models. The following screenshots show you how to export and import XMI in DB Visual ARCHITECT.

XML import and export

XML aid information system to share data. DB Visual ARCHITECT supports importing and exporting full or part of a project in XML format. The exported XML contains all information of Visual Paradigm project file. There is also an option to export diagram preview images together. The following screenshots demonstrate how to export and import XML.

Visual Paradigm project file import and export

DB Visual ARCHITECT supports exporting and importing full or part of a project to separate Visual Paradigm project file (.vpp). The following screenshots demonstrate how to export and import Visual Paradigm project file.

MS Excel file import and export

DB Visual ARCHITECT supports exporting and importing Microsoft Excel file. Excel is the best tool for mass editing of model element names and properties. You may export diagram to Excel file, edit their names and properties in tabular format, and then import the changes back to DB Visual ARCHITECT. The following screenshots demonstrate how to export and import Excel file.

Tutorial

Export database design to Excel for mass editing

UML2 model import and export

DB Visual ARCHITECT supports import and export Eclipse UML2 XML file. The following screenshots demonstrate how to import and export UML2 XML file.

Import Visio drawings

You may accumulate large amount of UML and database design drawing in Visio. DB Visual ARCHITECT imports Visio drawing into Visual Paradigm project format. You can keep all your Visio drawing in Visual Paradigm format. The following screenshots demonstrate how to import Visio drawing.

Import Visio diagram to Stencil

Reuse Visio diagram with UML diagrams by importing Visio Drawing to Stencil.

Import Rational Rose (mdl) files

DB Visual ARCHITECT imports all diagrams, model elements and properties from Rational Rose (mdl) file. You can keep and further maintain all your Rational Rose UML design in Visual Paradigm format. The following screenshots demonstrate how to import Rational Rose (mdl) file.

Import ERWin Data Modeler project files

DB Visual ARCHITECT imports AllFusion ERWin Data Modeler project files. You can import your entire AllFusion ERWin Data Modeler project files into Visual Paradigm format. The following screenshots demonstrate how to import AllFusion ERWin Data Modeler project file.

Import Telelogic Modeler project files

DB Visual ARCHITECT imports Telelogic Modeler project file. You can import your entire Telelogic Modeler project files into Visual Paradigm format. The following screenshots demonstrate how to import Telelogic Modeler project file.
