Requirement diagram

Requirement diagram

Requirement specifies capability or condition that must be delivered in the subject (target system). Capability usually refers to the function that the system must support and we call it functional requirement. Condition usually means that the system should be able to run or produce the result in specific constraint, and we call it non-functional requirement. Agilian provides a SysML requirement diagram for specifying and analyzing requirements. The following movie shows how to draw requirements, input detail of requirement (e.g. kind, verify method...), derive requirement and relate requirement with test case. The movie also shows how to switch between diagram view and tabular view. Finally, the movie demonstrates how to create or customize requirement types for your team.

Requirement grid

Enhanced feature
  • Supported showing sub-diagrams in grid

    Sub-diagram information can be shown in grid column.

  • Supported searching in grid

    Searching of grid content is available in the grid feature.

Requirement grid

Requirements gird provides a tabular view of all requirements in the project. You can create requirements in grid.

Block definition diagram

Visualize your system hierarchy. Define the system/component classifications in blocks to get a better picture of interconnections between these system components.

Internal block diagram

Take a closer look at your system design from within. Describe the internal structure of a system in terms of its parts, ports, and connectors.

Parametric diagram

A restricted form of internal block diagram that shows only the use of constraint blocks along with the properties they constrain within a context. The diagram is used to support engineering analysis, such as performance, reliability, and mass properties analysis.
