DB Visual ARCHITECT - Database design tool that supports ERD and UML class diagram

Database Visual ARCHITECT (DB-VA) is a database design tool that supports designing database with entity relationship diagram (ERD) and UML class diagram. DB-VA generates database initialization script (DDL), Java Hibernate mapping, .NET NHibernate mapping and PHP Doctrine mapping. DB-VA generates, reverse and synchronize Java and C++.

Database Design

• Draw ERD
• Generate class diagram
• Generate database

Report Generation

• Generate database spec.
• Design spec. template
• Publish to website

ORM Support

• Generate Hibernate
• Generate NHibernate
• Generate Doctrine

Visio Import

• Import ERD
• Import class diagram
• Keep all layout
